Portfolio

Nepal Earthquake Survey

Post Disaster Survey and Investigation for ensuring the structure’s stability, evaluating the risk of collapse and mitigation plan earthquake

Bullet Train Project

Rapid Seismic Venerability Survey (RVS) for structures along the rail line of bullet train as per different codal provision including BIS 4326:1993, 1893:2002 FEMA-154/ATC-21, EN and NZS 1170.5:2004 practicing code .

IIT Roorkee Campus

Pre-Disaster Survey of Academic to Residential & Hostel Building at IIT Roorkee campus for hazard mapping and evaluating the seismic vulnerability index associated with the old structures

kedarnath temple

Kedarnath Temple

Post Disaster Survey of Kedarnath Temple


Shanti Niketan - Jadavpur University

Stability and residual life assessment of sculpture built with mud, bamboo and lime

Jaisalmer Fort

Jaisalmer Fort

Structural Audit of Raja ka Mahal to evaluate the cause behind the settlement and out plane failure of masonry wall, Deflection, Crack and settlement monitoring

Writers Building

Writers Building

Structural health assessment of heritage structures along with repair and rehabilitation plan

Patna High Court

Patna High Court

Structural health assessment of heritage structures along with repair and rehabilitation plan

Khada Parsi Metal Statues

Khada Parsi Metal Statues

Age & Durability of Structure, Rate of corrosion in metal and required protective coating materials

Khada Parsi Metal Statues

Structural Conservation

Designing the Structural Conservation Scheme without Disturbing the Heritage Values of the Structure

Khada Parsi Metal Statues

Remedial/Strengthening

Remedial/Strengthening Measures including Preparation of Retrofitting Drawings. Our technologies include the scheme from the foundation strengthening to floor extension technique. Our Design is not limited up to CFRP to Grouting we analyze the scheme as composite material.

Khada Parsi Metal Statues

Cost-Effective Repair Technology

Cost-Effective Repair Technology, Cost estimation for repair and rehabilitation, Detailed BOQ, Technical Specifications, Rate Analysis, Complete DPR including the bid as well as tender documents

Khada Parsi Metal Statues

Construction Quality Audit

Project Management services, Periodic Quality Monitoring, Quality Assurance Management, Construction Quality Audit

Khada Parsi Metal Statues

Training Manual Design

Training Manual Design- Quality Manual for Skill Development Training Manuals for Site Engineers, Training to project staff

Khada Parsi Metal Statues

Repair and Maintenance handbook

Repair and Maintenance handbook

Khada Parsi Metal Statues

Indore Iron Mill

460 TMT Bar Design-Handbook Preparation

Khada Parsi Metal Statues

BASF

Certification of Master pale crystalline water proofing for Indian market

Khada Parsi Metal Statues

Saint- Gobain

Gyproc Drywall Material Standardization: - A comparative analysis between Masonry brick wall and Gyproc dry wall in terms of strength and seismic feasibility along with cost saving

Khada Parsi Metal Statues

Performance Certification of Corrosion Inhibitor

Performance evaluation of Corrosion inhibitor as per ASTM F 7105

Khada Parsi Metal Statues

Alumino-Pro -Façade Products

Performance of Anchor, Bolt, Couplers Embedded into RCC Sections, Structural Element’s Test, Pre-Cast Building Element Test, Panel & Facade Testing, Design Standardization of construction/repairing materials

Khada Parsi Metal Statues

Scaffolding and Support Design

Performance assessment for consumer product (CFRP, FRP Sheet, Brackets, Cladding, Façade, Hangers, Ducting etc.), Development of Customized Testing Program, scaffolding design and application procedure

Khada Parsi Metal Statues

Mahatma Gandhi-Setu

Crack Propagation, Grade of Concrete, Relaxation in post tensioning wires

Khada Parsi Metal Statues

KMDA – Kolkata

Structural Health Assessment including monitoring of Stain and stress level, Crack- depth and its width propagation, Temperature, humidity and Moisture Ingress, Tilting meter to settlement and scouring level monitoring

Khada Parsi Metal Statues

Scaffolding and Support Design

Performance assessment for consumer product (CFRP, FRP Sheet, Brackets, Cladding, Façade, Hangers, Ducting etc.), Development of Customized Testing Program, scaffolding design and application procedure

Khada Parsi Metal Statues

Bow & String - Three Hinge Arch Bridge

Static and Dynamic Load Test, residual life assessment following IRC SP 17 and IRC SP

Khada Parsi Metal Statues

Masonry Arch Bridge- Rail Bridge

FEM analysis, load carrying capacity, repair scheme for updated bogie load as per Railway Bridge handbook

Khada Parsi Metal Statues

Steel Rail Bridge

Performance analysis of bridge, condition survey of rivets, fatigue and other behavior along with condition survey of bearing.

Khada Parsi Metal Statues

North Western railways

Capacity analysis for Gauge conversion, NDT, Health assessment for evaluating the possibility to increase the load capacity of plain concrete pier

Khada Parsi Metal Statues

Composite Steel Box Bridge- Delhi PWD Flyovers

Composite behavior, Structural adequacy analysis, Thermal coefficient and Load Rating of bridges

Khada Parsi Metal Statues

SAIL - Aqueduct

Dynamic analysis of Overhead Aqueduct; Seepage, Corrosion and Maintenance program or scheme for the structure

Khada Parsi Metal Statues

Cable Stayed Bridge – BPCL

Tension and elongation monitoring of cable bridge, corrosion rate in wire, vibration monitoring and strain relaxation in cables

Khada Parsi Metal Statues

Fire Damage Analysis

Assessment of structural health after fire, source of fire, intensity of temperature, effects on embedded reinforcement, loss of strength and load carrying capacity of structures, fire Profile by DTA/TGA

Khada Parsi Metal Statues

Vibration Analysis

Impact of forced vibration on structure, floor design for robotic based operation, performance evaluation of isolation and vibration pad, possible damage risk in structure due to vibration generated from traffic, excavation, under ground metro or any heavy impact machine

Khada Parsi Metal Statues

Crack-Corrosion Monitoring

Crack depth and crack width monitoring with sensor and crackometer, crack tell-tale, crack pattern and Crack Profiling

Khada Parsi Metal Statues

Durability-Corrosion Investigation

Corrosion risk available in structure, reinforcement and steel members; loss of tensile strength or member’s section size, Leaching, Salt Deposition, Chemical Attack on Structure

Khada Parsi Metal Statues

Leakage and Underground Investigation

Locating the source of leakage, Leakage detection in pipeline, Layout profiling for plumbing/utilities system, under water survey of piles or bridge foundation

Khada Parsi Metal Statues

Collapse-Modification

Investigation and finding reason behind the Collapse of Silo and ESP Hopper, fire damage building, suggestion for repair and strengthening of the structure
